Faital Pro 12FE300 LF Driver

€ 106.00 *Standaard Prijs is RRP exclusief btw € 128.26 inclusief btw

Aantal

NOMINAL SPECIFICATIONS
Nominal Diameter	300 mm (12 in)
Overall Diameter	311 mm (12.24 in)
Bolt Circle Diameter	294 mm (11.57 in)
Baffle Cutout Diameter	284 mm (11.18 in)
Depth	133 mm (5.24 in)
Flange and Gasket Thickness	8 mm (0.31 in)
Net Weight	3.5 kg (7.7 lb)
Shipping Box	350 x 346 x 190 mm
(Single Carton Box)	(13.7 x 13.6 x 7.48 in)
Shipping Weight	4.3 kg (9.5 lb)


TECHNICAL PARAMETERS
Nominal Impedance	8 Ohm
Minimum Impedance	6.1 Ohm
AES Power Handling (1)	250 W
Maximum Power Handling (2)	500 W
Sensitivity (1W/1m)	97 dB
Frequency Range	50÷4000 Hz
Voice Coil Diameter	52 mm (2.05 in)
Winding Material	Cu
Former Material	Glass Fiber
Winding Depth	12.8 mm (0.50 in)
Magnetic Gap Depth	8 mm (0.31 in)
Flux Density	1.1 T
Magnet	Ferrite Ring
Basket Material	Steel
Demodulation	No
Cone Surround (3)	Triple Roll
NET Air Volume filled by Loudspeaker	2 dm^3 (0.071 ft^3)
Spider Profile	1x variable height waves
THIELE AND SMALL PARAMETERS
Fs	47 Hz
Re	5.1 Ohm
Qes	0.53
Qms	15.5
Qts	0.51
Vas	83.7 dm^3 (2.96 ft^3)
Sd	543 cm^2 (84.17 in^2)
Xmax (4)	5.07 mm
Xdamage (5)	16.7 mm
Mms	56.4 g
Bl	12.5 N/A
Le	0.8 mH
Mmd	42.1 g
Cms	0.20 mm/N
Rms	1.1 kg/s
Eta Zero	1.55 %
EBP	89 Hz
