Faital Pro 15FH520 LF Driver

€ 321.00 *Standaard Prijs is RRP exclusief btw € 388.41 inclusief btw

Op bestelling leverbaar

Aantal

NOMINAL SPECIFICATIONS
Nominal Diameter	380 mm (15 in)
Overall Diameter	393 mm (15.47 in)
Bolt Circle Diameter	374 mm (14.72 in)
Baffle Cutout Diameter	356 mm (14.02 in)
Depth	181.3 mm (7.14 in)
Flange and Gasket Thickness	13.7 mm (0.54 in)
Net Weight	4.6 kg (10.1 lb)
Shipping Box	430 x 427 x 236 mm
(Single Carton Box)	(16.9 x 16.8 x 9.3 in)
Shipping Weight	5.7 kg (12.6 lb)


TECHNICAL PARAMETERS
Nominal Impedance	8 Ohm
Minimum Impedance	6.9 Ohm
AES Power Handling (1)	600 W
Maximum Power Handling (2)	1200 W
Sensitivity (1W/1m)	98 dB
Frequency Range	40÷4000 Hz
Voice Coil Diameter	77 mm (3 in)
Winding Material	Al
Former Material	Glass Fiber
Winding Depth	21.5 mm (0.85 in)
Magnetic Gap Depth	12 mm (0.47 in)
Flux Density	1.1 T
Magnet	Neodymium Slug
Basket Material	Aluminum
Demodulation	Aluminum Ring
Cone Surround (3)	Triple Roll
NET Air Volume filled by Loudspeaker	3.4 dm^3 (0.120 ft^3)
Spider Profile	1x variable height waves
THIELE AND SMALL PARAMETERS
Fs	36 Hz
Re	5.6 Ohm
Qes	0.41
Qms	10.1
Qts	0.39
Vas	186.5 dm^3 (6.59 ft^3)
Sd	847 cm^2 (131.29 in^2)
Xmax (4)	8.75 mm
Xdamage (5)	16 mm
Mms	105 g
Bl	18.4 N/A
Le	0.89 mH
Mmd	77.1 g
Cms	0.19 mm/N
Rms	2.4 kg/s
Eta Zero	2.15 %
EBP	88 Hz
