Faital Pro 6HX150 Coaxial Driver

€ 244.00 *Standaard Prijs is RRP exclusief btw € 295.24 inclusief btw

Op bestelling leverbaar

Aantal


NOMINAL SPECIFICATIONS
Nom. Diameter	160 mm (6 in)
Overall Diameter	186.5/162 mm (7.34/6.37 in)
Bolt Circle Diameter	172 mm (6.77 in)
Baffle Cutout Diameter	147 mm (5.79 in)
Depth	95 mm (3.74 in)
Flange and Gasket Thickness	9.3 mm (0.37 in)
Net Weight	1.3 kg (2.9 lb)
Shipping Box	202 x 202 x 134 mm
(Single Carton Box)	(8.0 x 8.0 x 5.3 in)
Shipping Weight	2.8 kg (6.2 lb)



TECHNICAL PARAMETERS	{ LF }	{ HF }
Nom. Impedance	8 Ohm	8 Ohm
Minimum Impedance	6 Ohm	6.3 Ohm
AES Power Handling (1)	150 W	15 W
Max Power Handling (2)	300 W	30 W
Sensitivity (1W/1m) (3)	93 dB	104 dB
Frequency Range	90÷5000 Hz	1500÷18000 Hz
Voice Coil Diameter	52 mm (2 in)	25 mm (1 in)
Winding Material	Cu	Al
Former Material	Glass Fiber	Kapton
Winding Depth	10.7 mm (0.42 in)	1.7 mm (0.07 in)
Magnetic Gap Depth	6 mm (0.24 in)	2 mm (0.08 in)
Flux Density	1.35 T	1.3 T
Min. Cross. Freq. (4)	-	1.7 kHz
Dispersion Angle	-	90°
Diaphragm Material	-	Ketone Polymer
Diaphragm Shape	-	Dome
Magnet	Neodymium Ring	Neodymium Ring
Basket Material	Aluminum	-
Demodulation	Aluminum Ring	-
Cone Surround (5)	Half Roll	-
NET Air Volume filled by Loudspeaker	0.6 dm^3 (0.021 ft^3)	-
Spider Profile	1x constant height waves	-

THIELE AND SMALL PARAMETERS { LF }
Fs	88 Hz
Re [LF]	5.5 Ohm
Re [HF]	6 Ohm
Qes	0.35
Qms	8.3
Qts	0.34
Vas	6.3 dm^3 (0.22 ft^3)
Sd	139.2 cm^2 (21.58 in^2)
Xmax (6)	4.35 mm
Xdamage (7)	10.15 mm
Mms	14 g
Bl	12 N/A
Le	0.64 mH
Mmd	12.1 g
Cms	0.23 mm/N
Rms	0.9 kg/s
Eta Zero	1.41 %
EBP	251 Hz
